Semiconductor Industry Sky-Tag's Machine

Fully Auto OS Test Handler

Product Description

An automatic system for the test of processor. The system was built with integration of robotic arm. The system can accommodate up to 20 trays of processor at the loading and unloading buffer tray. Operator only have to come back every 30 mins for loading and unloading.

Process Description

Operator manually load and unload 20 trays of processor each time. Robotic arm is used to pick and place to unload the processor onto the test socket. The tester will communicate with checksum tester for open short testing. After testing, the robotic arm will pick and place to remove the processors and arranged in red rejected and green accepted tray according to the test.
